Girouettes Bus – Présentation

Enclosure

  • Aluminum structure
  • Acrylic back side
  • Lightweight and easy to handle
  • Poids entre 1,1kg et 3Kg selon Modèle.
  • 15W to 60W depending on model
  • Hauteur Caractères maximale : 19,2 cm (modèle P6)

5 standard dimensions

  • 1,18 m x 22 cm x 5,5 cm Pitch 6mm (P6) 60W
  • 99 cm x 19 cm x 5,5 cm Pitch 5mm (P5) 40W
  • 80 cm x 16 cm x 4 cm Pitch 4mm (P4) 25 W
  • 54 cm x 16 cm x 4 cm Pitch 4mm (P4) 20W
  • 41 cm x 12 cm x 4 cm Pitch 3mm (P3) 15W

Any other dimension possible on request

Front-facing

  • SMD Leds
  • Pixel pitch 3, 4 , 5 or 6 mm RGB
  • Brightness> 1600 cd/m2 (P3 and P4), 6000 cd/m2 (P5)
  • Maximum viewing angle: 140° H/V
  • Indoor use (IP20-IP43)
  • Operating temperature: -20°C to +55°C
  • Ambient humidity: 10%-95% RH
  • Power supply 12V and 24V (70W Max depending on model)

Fasteners

2 side strong suction cups 6cm in diameter.

Possibility of fixing by brackets (Contact us)
